Installation Instructions for Lima Thermostatic LED Shower System
First, unbox everything to ensure that all the tools and components are present in installing this BathSelect Lima Thermostatic LED Shower System: a wrench, screwdriver, and fittings. Ensure the water supply is turned off; remove the old shower fixture and prepare the installation area. Mount the thermostatic valve into the wall, making certain it's level and securely fastened. Connect the hot and cold-water supply lines to the corresponding valve ports, sealing by wrapping the threads with Teflon tape. Afterwards, install the showerhead and hand shower, making sure it is aligned and then secured properly. Connect the LED light connections in accordance with the wiring diagram supplied. This is where extreme caution has to be taken as far as electrical safety goes. When all is set, turn the water supply on and inspect for leaks and problems in water flow. Check to see if the thermostatic controls provide the right regulation of temperature, verify that the LED lights do their job accordingly. Do necessary adjustments and clean up the area to finish the installation of your BathSelect Lima Thermostatic LED Shower System.
|
Installation Instructions for Lima Thermostatic LED Shower System
|
|
Remarks: Ceiling mounted shower head come with fixing bar installation
1. Draw size on ceiling
2. Install fixing bar on ceiling
3. Install fixing bar on shower head
4. Put shower head bar on ceiling fixing bar.
The showerhead installation is now complete.
|
