Bravat Wall Mount Brushed Gold Shower Set With Thermostatic Valve Mixer Concealed

The Bravat Brushed Gold Shower Set With Valve Mixer Concealed Wall Mount is one of the most trendiest finishes across decor styles in the bathroom. It has a contemporary style with a beautiful Dark Oil Rubbed Bronze finish. Turn on the fun in your shower and experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress just by turning on the water in a high-pressure bathroom head shower with 360° 6 adjustable body spray jets and a hand shower. Bravat Brushed Gold Shower Valve Mixer Concealed Wall Mounted Features: Brand Name: BathSelect Model Number: BS1066 Type: Shower Set & Shower Mixer Style: Contemporary Type: Fixed Support Type Surface Finish: Brushed Gold Installation Type: Wall Mount Control Type: Single Holder Dual Control Size: 7.91"-11.85" (201-300mm) Surface Treatment: Polished Valve Core Material: Ceramic Bath Shower Type: In-Wall Shower Mixer Valve Type: Ceramic Valve Faucet Handle Material: Zinc Alloy Mixer Body Material: Brass Valve Included: Yes Embedment Depth: 2.16" (55mm) Valve Panel Dimension: 6.29"x6.29" (160x160mm) Connector: G1/2"B (Standard) athSelect® Manufacturer Warranty Information Before you begin, please read the installation instructions below. Observe all local building and safety codes. Unpack and inspect the product for any shipping damages. If you find damages, do not install. Please note all showers must be installed by a professional and certified plumber otherwise warranty may be voided.

shower

Shower

Shower Head Installation Instructions

	Shower Head Parts Included: Wall Mounting Arm Locking nut Wall trim Shower arm Showerhead Fixing screws and wall plugs (not shown)

Step 1:		Step 2:		Step 3:
Wall Mount Round Showerhead	Showerhead		Showerhead
Wall Mount Round Showerhead
Step 4:		Step 5:		Step 6:
Wall Mount Round Showerhead

1. Remove the old shower head by using the channel lock pliers or monkey wrench. Be sure to turn the pliers counter-clockwise to loosen the old shower head. (Tip: Right is tight, left is loose.) 2. Remove the shower arm by turning it by hand counter-clockwise. Make sure you remember to apply putty or tape to the new arm. (Tip: Using teflon tape is less messy) 3. Apply teflon tape to the threading of the shower arm by wrapping it around the threads, go all the way around 3 or 4 times depending on the quality of the Teflon tape. 4. Install the new shower arm by going clockwise by hand until it is tight, then put painters tape around the arm and tighten the arm with the channel lock or monkey wrench. 5. Place Teflon tape around the threads on the shower head and then place the shower head onto the shower arm by turning the shower head clockwise after the shower arm is already in the wall.

HandHeld Shower Installation Instructions

Hand-Held Shower Installation Instructions

HandHeld Shower Installation Instructions

Step 1:		Step 2:		Step 3 & 4:
	Hand Held Shower		Hand Held Shower
Handheld Shower		Handheld Shower		Handheld Shower
Step 5:		Step 6 & 7:		Step 8:

1. Gather All Parts 2. Hole Locations For Wall Mount Remove Front Cover (A) from Wall Mount (B). Use Wall Mount Screw Holes (C) to place the desired location. Using a punch or awl, tap the screw hole locations. Holes must be vertically aligned. 3. Anchor Installation Drill two 1/4” dia. Holes (A). If installing into a studs drill two 1/8” dia. holes and do not use Anchors (B). Insert Anchors (B) into Holes (A) and tap flush with the wall. 4. Wall Mount Installation Place Wall Mount (A) into wall and inset Mounting Screws (B) through Wall Mount Holes (C) and tighten until Wall Mount (A) is flush with the wall. Do Not Over Tighten! Insert Front Cover (D) into Wall Mount (A) 5. Drop Elbow & Hose Installation Apply PTFE plumbers tape on both ends of Pipe Nipple (A) (not included). Screw Pipe Nipple (A) into the elbow inside the wall. The Pipe Nipple (A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (B) onto Pipe Nipple (A) and tighten until Drop Elbow (B) is property positioned and flush to the finished wall. Place Rubber Seal (C) inside Hex Hose Fitting (D). Connect Hex Hose Fitting (D) into Drop Elbow Outlet (E) by turning Hex Hose Fitting (D). 6. Unit Startup Turn on hot and cold water supplies, and check all connections for leaks. 7. Final Flushing For final flushing, turn the valve on and allow water to run through the Hose (A) for several minutes. Allow water to run for several minutes until all foreign matter clears the line. 8. Shower Arm Installation Place Rubber Seal (A) inside Tapered Hose Fitting (B). Conned Hand Shower (C) to Hose (D) by turning Tapered Hose Fitting (B ) clockwise. Warning: Make sure Hand Shower (C) is securely tightened to Hose (D).

Thermostatic Valve Mixer Installation Instructions

Mixer Installation Instructions

Step 1:	Mixer	Step 2:
	Thermostatic Valve Mixer
Close the stops. Cut the plaster shield so that it extends ¹⁄₁₆" - ⅛" from the finished wall surface.		Seal the wall around the plaster shield with a waterproof sealant. Remove the flush insert and the flush insert seals.
Thermostatic Valve Mixer Installation Instructions
Step 3:		Step 4:
