Thermostatic Mixer
|
Step 1:
|
mixer
|
Step 2:
|
|
|
|
|
|
|
mixer
|
|
|
1) Fix the shower valve into the wall with screws. Use a level to ensure that the valve is straight and level. (Important: Flush the water supply pipes to remove any dirt and debris before installing the valve body)
2) Wrap Teflon tape around the pipe thread. Connect hot and cold water supply lines and all the in-wall pipes(not included) as desired to the valve. Turn on the water supply and open the cartridge to check for leaks. Then, put on the protective cover.
3) Remove the protective cover when the wall finished wall is completed. Install escutcheon onto the shower valve and press it against the finished wall. Then, install the handle and diverter knob to the valve and tighten set screws with the Allen key and put on the indication button.
Hand-Held Shower Installation Instructions
Step 1
|
|
Step 2
|
- Open the closed cover of the shower holder and take out the screws.
- Drill two holes size 0.2" (6mm) on the wall according to the hole position of the shower holder.
- Use a hammer to break 2 plastic wall plug into two holes. Tighten the screws with the plastic wall plug and locking with the shower holder. Then install the closed cover.
- Connect the shower hose with the water outlet connection part and hand shower. Plug the hand shower in the shower holder.
